Clearance Hole Calculator

Determine standard through-hole drill diameters for metric bolts and machine screws based on ISO 273 Close, Medium, and Free fit classes.

Reviewed by Best Calculators Editorial Team Updated: Free Tool

Fastener & Fit Parameters

Select metric screw thread size and designated fit tolerance.

Machining Drill Specs

Conforms to ISO 273 standard.

Recommended Drill Bit Size
Clearance Hole Diameter
6.6 mm
Dimensional Breakdown
Nominal Bolt Diameter 6 mm
Diametral Clearance +0.6 mm
Radius Gap per Side 0.3 mm

What is a Clearance Hole?

A clearance hole is an unthreaded, cylindrical passage machined or drilled through a structural component that is intentionally sized slightly larger than the external major diameter of the threaded fastener intended to pass through it. The foundational objective of a clearance hole is to allow the bolt shank or machine screw to slide through freely without the external threads biting into or binding against the through-plate.

In mechanical joint design, proper clamping force requires that the fastener tension acts strictly between the underside of the bolt head and the internal threads of the mating tapped hole or hex nut. If a hole is drilled too small, the bolt threads seize against the walls of the through-plate, generating false torque readings and severely diminishing clamping pre-load. Conversely, drilling a hole excessively large reduces the bearing surface area beneath the bolt head, leading to flange distortion and structural joint loosening under dynamic operational vibration.

Fabricators and structural engineers frequently coordinate clearance hole specifications with load-bearing structural assessments using our Beam Load Calculator, evaluate structural deflections with our Cantilever Beam Calculator, and estimate raw raw material weights using our Metal Weight Calculator.

How Clearance Hole Dimensions Work (ISO 273 Standards)

International engineering standards (specifically ISO 273, DIN EN 20273, and ASME B18.2.8) establish precise standardized clearance hole diameters based on nominal thread diameters and designated assembly fit classifications:

Clearance Hole Diameter (D_h) = Nominal Bolt Diameter (d) + Diametral Clearance (c)
Radial Gap per Side (g) = (D_h - d) / 2

1. The Three Standard ISO 273 Fit Classes

  • Close Fit (Fine Series): Specifies the minimum allowable hole diameter that permits fastener entry without binding. Recommended for precision tooling, locating pins, dynamic mechanism alignment, and assemblies where lateral component play must remain minimal.
  • Medium Fit (Normal Series): Represents the universal default standard for general mechanical engineering, structural steel framing, automotive sub-assemblies, and industrial fabrication. Balances ease of manual assembly with solid joint clamping rigidity.
  • Free Fit (Coarse Series): Provides generous radial clearances to accommodate large manufacturing position tolerances, thermal expansion differentials, rough cast-iron components, or heavily hot-dip galvanized and powder-coated fasteners.

2. Step-by-Step Worked Example

Consider an engineer designing a structural steel connection secured by an M12 metric hex bolt (nominal major diameter = 12.0 mm):

  • Under Close Fit, ISO 273 specifies a hole diameter of 13.0 mm (diametral clearance = +1.0 mm, radial gap = 0.5 mm).
  • Under Medium Fit (general engineering), ISO 273 specifies 13.5 mm (diametral clearance = +1.5 mm, radial gap = 0.75 mm).
  • Under Free Fit (loose fabrication), ISO 273 specifies 14.5 mm (diametral clearance = +2.5 mm, radial gap = 1.25 mm).

Selecting a standard 13.5 mm twist drill bit satisfies the Medium Fit specification, enabling rapid field assembly while maintaining optimal bearing contact beneath a standard ISO 7089 hardened structural washer.

Key Engineering Concepts in Fastener Joint Design

Achieving durable, fatigue-resistant mechanical joints requires understanding several complementary physical properties:

True Position & Positional Tolerance

In multi-hole bolt patterns, slight CNC spindle or manual drill press positional inaccuracies can accumulate. If four bolt holes deviate by 0.3 mm from true center, a Medium or Free Fit clearance hole accommodates the pattern shift without binding.

Clamping Pre-load vs. Thread Friction

Tightening torque applied to a bolt must generate axial tensile stretch (pre-load) that clamps joint faces together. A proper clearance hole prevents false torque absorption along the upper plate thickness.

Bearing Stress & Washer Support

Excessively large clearance holes reduce the contact bearing area under bolt heads. High pre-load forces can compress or dish thin aluminum or plastic parts, necessitating heavy-gauge flat washers.

Thermal Expansion Differential

When bolting materials with disparate thermal coefficients (such as aluminum fastened to structural carbon steel), Free Fit clearance holes provide necessary expansion space during temperature shifts.

For related architectural and facility planning tools, builders also reference our Air Changes per Hour Calculator and staircase calculation guides like the Stair Carpet Calculator.

How to Use the Clearance Hole Calculator

Follow this simple machining setup workflow to determine the proper drill size for your fasteners:

  1. Select Nominal Metric Fastener: Pick your designated screw or bolt size from the dropdown menu, ranging from miniature M1.6 machine screws up to heavy M36 structural bolts.
  2. Choose Fit Class: Select Close Fit for high-precision tooling, Medium Fit for standard shop machining, or Free Fit for rough construction and galvanized hardware.
  3. Click Calculate: Review the exact recommended hole diameter in millimeters, the nominal bolt shank size, and the net clearance gap.
  4. Select Drill Tooling: Equip your drill press or CNC milling center with a standard twist drill bit or end mill matching the calculated hole diameter.

Benefits of Standardized Clearance Hole Sizing

Conforming to established international clearance hole standards provides essential commercial and mechanical benefits:

  • Eliminates Fastener Binding and Galling: Ensures stainless steel and alloy fasteners slide cleanly through joint plates, preventing thread galling and incomplete pre-load torque.
  • Accelerates Production Assembly: Assembly line workers and field mechanics can insert bolts smoothly by hand without utilizing mallets or reaming holes during final erection.
  • Ensures International Interchangeability: Designing fabrication drawings to ISO 273 ensures that parts machined across different facilities fit together consistently without modification.
  • Optimizes Structural Fatigue Life: Correct clearance dimensions distribute clamping stress evenly around hole margins, mitigating local stress concentration factors that induce fatigue cracking.

Key Machining and Environmental Considerations

Before releasing mechanical drawings to manufacturing, evaluate these practical fabrication and environmental factors:

1. Multi-Hole Pattern Positional Accuracy

If fabricating bolt circles or matrix patterns using manual layout punches rather than CNC centers, specify Medium or Free Fit to forgive slight manual drill walking.

2. Surface Finishing and Galvanizing Build-Up

Heavy zinc coatings and multi-coat epoxy primers reduce clear hole diameters by 0.1 to 0.25 mm. Account for post-machining coating thickness when selecting fit classes.

3. Soft Base Materials

When clamping soft woods, fiberglass composites, or thermoplastics, oversize holes allow fastener heads to sink under torque. Pair clearance holes with wide-flange fender washers.

4. Countersink and Counterbore Integration

Socket head cap screws require counterbored clearance pockets. Ensure the outer counterbore diameter accommodates standard socket tool wall clearances.

For global fastener specifications and mechanical engineering guidelines, explore publications from the International Organization for Standardization (ISO) and technical fastener engineering resources from the American Society of Mechanical Engineers (ASME).

Frequently Asked Questions

What are the three classes of clearance holes defined by ISO 273?

ISO 273 defines three standardized clearance hole fit classes: Close Fit (Fine) for precision assemblies requiring minimal lateral play and exact component alignment; Medium Fit (Normal) for standard commercial machining, general fabrication, and general engineering applications; and Free Fit (Coarse) for loose assemblies, thermal expansion accommodation, or heavily painted and galvanized components.

Why is a clearance hole necessary in bolted structural joints?

A clearance hole allows a bolt or threaded fastener to pass through a non-threaded mating part without binding. By ensuring the bolt shank does not engage threads in the through-hole, the entire tightening torque translates into clamping tension between the fastener head and the threaded base, preventing joint separation.

How much larger than the fastener should a clearance hole be?

The oversize clearance depends on fastener diameter and designated fit class. For small fasteners such as M3, clearance ranges from +0.2 mm (Close) to +0.6 mm (Free). For medium structural fasteners such as M12, clearance increases from +1.0 mm (Close) to +2.5 mm (Free). Large structural bolts like M36 specify clearances from +1.0 mm to +6.0 mm.

Can standard fractional or metric twist drill bits produce ISO clearance holes?

Yes, standard jobber drill bits are commonly manufactured in 0.1 mm incremental steps in metric systems and 1/64-inch steps in imperial systems. Selecting standard twist drill bits that correspond to the ISO 273 recommended diameter yields appropriate engineering clearances without custom reamers.

What is the difference between a clearance hole and a tap drill hole?

A clearance hole is drilled larger than the fastener major outside diameter so the bolt slides through freely without threads. A tap drill hole is drilled smaller than the bolt major diameter (approximately equal to the thread minor diameter) so an internal tap can cut mating female threads into the hole wall.

When should an engineer specify a Close Fit clearance hole?

Close Fit holes should be specified in precision tooling, aerospace assemblies, dowel-aligned fixtures, and high-frequency cyclical load machinery where relative component shifting or shear slippage must be minimized. Close Fit requires tight CNC coordinate drill positioning tolerances.

How does hot-dip galvanizing affect clearance hole sizing?

Hot-dip galvanizing deposits a protective zinc coating layer that typically measures 50 to 120 microns (0.05 to 0.12 mm) in thickness on both fastener threads and hole walls. Specifying a Free Fit clearance hole prevents bolt binding caused by heavy molten zinc accumulation in through-holes.

What is the relationship between clearance hole diameter and washer selection?

When using Free Fit clearance holes with oversized diameters, the fastener head or nut bearing area may not fully overlap the hole margin. Installing a hardened flat washer (conforming to ISO 7089 or DIN 125) prevents the bolt head from dishing or pulling through the joint under high torque.
