A dry well size calculator is an engineering and landscaping tool that determines the required storage volume and excavation dimensions for an underground stormwater dry well. By calculating runoff from impervious roof or patio areas during design rainstorms, the calculator specifies exact pit dimensions, gravel stone tonnage, and modular unit quantities required to prevent yard flooding and foundation erosion.

• • Roof Downspout Runoff Capture: Sizing underground pits to safely collect and disperse roof water discharged from downspouts without pooling near home foundations.
• • Driveway & Patio Drainage: Managing surface storm runoff from non-porous concrete or paver surfaces to eliminate puddles and meet municipal stormwater infiltration codes.
• • Sump Pump & French Drain Discharge: Providing a dedicated sub-surface gravel absorption reservoir for basement sump pumps or perimeter French drains.
• • Low-Impact Development (LID) Compliance: Meeting local civil ordinances that mandate on-site retention for post-construction stormwater volume increases.

A dry well functions as a temporary sub-surface holding tank, capturing surge volumes during heavy downpours and slowly discharging that moisture into the surrounding native subsoil through natural infiltration. Properly sizing the well prevents water from overflowing onto lawns, pooling against foundation footings, or overwhelming municipal storm sewers.

Whether you build a traditional pit packed with clean washed aggregate or install high-efficiency modular plastic chambers, using a dry well size calculator ensures accurate sizing by balancing total inflow surge against the void storage ratio and native soil percolation rates.

For homes routing groundwater through perforated trench pipes before discharging into a collection pit, our French Drain Calculator provides complementary gravel and trench dimensions.

The dry well sizing calculation relies on standard hydrology mass-balance formulas to establish required surge volume and physical pit dimensions.

• Catchment Area: Total impervious drainage surface area in square feet.
• Rainfall Depth: Design storm precipitation depth in inches (e.g., 1.5 inches for a standard 24-hr design storm).
• C (Runoff Coefficient): Dimensionless coefficient representing surface impermeability (0.95 for asphalt shingle roofs).
• Stone Void Ratio: Porosity of the fill material (0.40 for clean washed gravel, 0.95 for modular hollow tanks).
• Pit Depth: Vertical excavation depth in feet, maintaining required clearance above seasonal groundwater.

Because water cannot occupy the space taken by solid stones, aggregate-filled pits require 2.5 times the volume of the raw stormwater runoff (1 / 0.40 = 2.5). In contrast, hollow modular polypropylene dry wells provide nearly 95% void space, dramatically cutting the excavation diameter and soil hauling costs.

Soil percolation rates directly govern dissipation speed. A well must fully drain within 24 to 48 hours to regenerate complete holding capacity before consecutive storm systems arrive.

According to US Environmental Protection Agency (EPA), clean washed stone aggregate provides approximately 40% void space for stormwater retention, and dry wells must be sized to hold design storm volumes.

To calculate material costs and delivery truckload quantities for the clean aggregate bedding, use our Gravel Calculator.

Designing an effective underground stormwater infiltration system requires understanding these core geotechnical concepts:

Neglecting void ratio is the most common sizing mistake in DIY drainage installations. Digging a hole equal only to the liquid runoff volume results in immediate surface overflow as soon as the stone aggregate is poured in.

Pretreatment with an inline catch basin or sediment leaf filter is essential. Keeping organic debris, leaves, and roofing grit out of the dry well prevents gradual siltation and preserves long-term infiltration performance.

When selecting backfill aggregates, consult our Crushed Stone Calculator to compare weight densities across various stone gradations.

Follow these practical steps and use the dry well size calculator to determine and construct an appropriately sized dry well on your property:

1. 1 Measure Contributing Catchment Area: Calculate the footprint of roof planes or impervious patio sections routing downspouts to the well in square feet.
2. 2 Determine Design Rainfall Depth: Select your local municipal 10-year or 24-hour storm design depth (typically 1.0 to 2.0 inches across most temperate regions).
3. 3 Conduct a Soil Percolation Test: Excavate a 12-inch test hole at the intended site, saturate the ground, and measure the rate of water level drop in inches per hour.
4. 4 Select Well Structure Type: Choose between a washed stone gravel pit (40% void), a modular plastic retention tank (95% void), or a concrete dry well ring.
5. 5 Review Excavation Dimensions & Order Materials: Review the required pit diameter, depth, washed gravel tonnage, and modular unit count from the calculator results.

For a 1,200 sq ft garage roof discharging into two downspouts during a 1.5-inch storm, selecting a 5-foot deep gravel pit shows you need an excavated diameter of 9.5 feet, requiring 18.5 tons of washed No. 3 gravel.

If your dry well will receive discharge from a basement sump pit, our Sump Pump Calculator verifies total dynamic head and flow capacities.

Properly calculating and constructing a dry well provides substantial property and environmental advantages:

• • Foundation & Basement Protection: Intercepts concentrated roof deluge and diverts moisture away from basement walls and foundation footings, eliminating hydrostatic pressure.
• • Eliminates Surface Pooling & Mosquito Breeding: Drains water underground into gravel beds within hours, preventing soggy lawns, turf kill, and standing insect breeding pools.
• • Natural Groundwater Aquifer Recharge: Replenishes local underground aquifers by filtering rainwater through subsoil rather than wasting it into municipal storm sewers.
• • Erosion & Mud Control: Neutralizes high-velocity downspout discharge that gouges landscape mulch, washes out topsoil, and creates yard ruts.
• • Regulatory & Code Compliance: Satisfies civil drainage ordinances requiring zero net increase in post-development stormwater discharge off residential lots.

Investing in a correctly sized dry well eliminates recurring landscape repairs and protects valuable structural investments from catastrophic water damage.

Unlike open retention ponds or large surface swales, dry wells remain completely hidden underground, preserving usable yard space for lawn activities, patios, and gardening.

To calculate the peak discharge rate moving through your feeder PVC pipes during peak deluge, try our Water Flow Rate Calculator.

Several critical geological, structural, and environmental factors influence dry well performance and sizing:

• • Not suitable for locations with impenetrable shallow bedrock or perched water tables within 2 feet of the excavation bottom.
• • Cannot receive contaminated runoff containing petroleum, automotive fluids, or toxic chemicals without specialized oil-grit separators.

In areas with slow-draining clay soils (perc rate below 0.5 inches per hour), dry wells should be designed wider and shallower to maximize the horizontal bottom infiltration surface.

Always incorporate an overflow pop-up relief emitter downstream so that extreme storms exceeding the design capacity can safely spill across lawn surfaces without backing up into roof gutters.

According to Penn State Extension, impervious residential roofs have a runoff coefficient of approximately 0.95, meaning 95% of rainfall immediately becomes surface runoff.
