Use this belt length calculator to find the total belt length and the wrap angle on each pulley for any open belt, crossed belt, or V-belt drive from two pulley diameters and the center-to-center distance.
Belt Length Calculator
Results
What Is a Belt Length Calculator?
A belt length calculator takes two pulley diameters and the center-to-center distance and returns the total belt length for an open, crossed, or V-belt drive, plus the wrap angle on each pulley.
- • Sizing a replacement drive belt: Enter the two pulley diameters and the center distance, then read the total belt length needed for the drive. The result is the cut length for a flat belt or the standard V-belt size to order.
- • Designing a new two-pulley drive: Sketch the drive by picking a center distance and two pulley diameters, then confirm the belt length before buying components.
- • Physics and machine-design homework: Solve textbook problems that ask for the length of an open or crossed belt drive or the arc of contact on each pulley.
- • Crossed and V-belt checks: Switch the belt mode in the panel to compute a crossed belt length or add the V-belt cross-section correction to the open-belt result.
The total belt length is the sum of the two straight runs between the pulley tangent points and the two arcs of contact on the pulleys. For an open belt the formula reduces to L = 2*C + (pi/2)*(D1 + D2) + (D1 - D2)^2 / (4*C); for a crossed belt the correction term uses (D1 + D2)^2 instead.
When the next step after sizing the belt is to confirm how much torque and power the same drive can transmit at the chosen RPMs, the torque, power, and speed calculator returns power from torque and rotational speed in the same panel.
How the Belt Length Calculator Works
This belt length calculator reads the two pulley diameters and the center distance, applies the textbook formula for the selected drive mode, and reports the total belt length and wrap angles.
- D1: Outer diameter of the first (usually larger) pulley in the same units as the center distance.
- D2: Outer diameter of the second pulley in the same units as the center distance.
- C: Center-to-center distance between the two pulley shafts.
- L_open: Total belt length on an open belt drive.
- L_crossed: Total belt length on a crossed belt drive.
- L_vbelt: Total V-belt length, which adds a small constant for the V-belt cross-section height to the open-belt pitch-line result.
- Wrap angles: Arc of contact on each pulley in degrees, equal to 180 + 2*arcsin((R1 - R2)/C) for the larger pulley and 180 - 2*arcsin((R1 - R2)/C) for the smaller pulley on an open belt.
The wrap-angle rows come from the same geometry. For an open belt, the larger pulley wraps 180 + 2*arcsin((R1 - R2)/C) degrees and the smaller pulley wraps 180 - 2*arcsin((R1 - R2)/C) degrees. For a crossed belt the two wrap angles are equal.
Worked example: equal 100 mm pulleys with 400 mm center distance on an open belt
D1 = 100 mm, D2 = 100 mm, C = 400 mm, open belt.
L = 2*400 + (pi/2)*(100 + 100) + (100 - 100)^2 / (4*400) = 800 + 100*pi + 0 = 1114.16 mm.
Total belt length = 1114.16 mm. Wrap angle on each pulley = 180 degrees.
Equal pulleys make the correction term zero, so the formula reduces to twice the center distance plus the full circumference of one pulley.
According to Omni Calculator - Belt Length, the open belt length on two pulleys is L = 2*C + (pi/2)*(D1 + D2) + (D1 - D2)^2 / (4*C) and the crossed belt length is L = 2*C + (pi/2)*(D1 + D2) + (D1 + D2)^2 / (4*C), with a small V-belt correction added for the V-belt cross-section height.
According to Wikipedia - Belt (mechanical), open belt length is 2*C + (pi/2)*(D1 + D2) + (D1 - D2)^2 / (4*C), crossed belt length is 2*C + (pi/2)*(D1 + D2) + (D1 + D2)^2 / (4*C).
When the same two-pulley drive is being driven through a gear pair instead of a belt, the gear ratio and RPM calculator returns the speed ratio and the driven RPM from the two pitch diameters and the motor RPM.
Key Concepts Explained
Four concepts make the formula behave the way it does.
Why the formula splits into straight runs plus half a circumference
The belt has two straight runs between the tangent points and two arcs of contact on the pulleys. The two arcs together always cover exactly half the circumference of a circle whose diameter is D1 + D2.
Why the correction term is (D1 - D2)^2 / (4*C)
When the pulleys are different sizes, the tangent points do not line up with the shafts, so the two straight runs are slightly longer than 2*C by an amount that scales with (D1 - D2)^2 / (4*C). When D1 = D2 the correction term is zero.
Why a crossed belt swaps the difference for the sum
In a crossed belt the straight runs cross between the pulleys, so each one has to swing around the other pulley. The extra swing adds a length that scales with (D1 + D2)^2 / (4*C) instead of (D1 - D2)^2 / (4*C).
Why V-belt adds a small constant
A V-belt rides on the pitch diameter rather than the outer diameter, and the belt body above the pitch line adds a few millimetres to the cut length.
The wrap-angle readouts collapse these concepts into numbers. Equal pulleys give exactly 180 degrees on each pulley and a zero correction term. Unequal pulleys push the larger pulley above 180 degrees.
When the question is how much a tensioned belt stretches under the working load, the spring constant and deflection calculator returns the spring constant, deflection, and elastic potential energy for the same Hooke's-law geometry.
How to Use This Calculator
Six short steps are enough to size an open belt, crossed belt, or V-belt drive.
- 1 Measure or pick the larger pulley diameter D1: Type the outer diameter of the first pulley in the Pulley 1 diameter (D1) field, in millimetres.
- 2 Measure or pick the smaller pulley diameter D2: Type the outer diameter of the second pulley in the Pulley 2 diameter (D2) field, in the same units as D1.
- 3 Enter the center-to-center distance C: Type the distance between the two pulley shafts. It must be greater than (D1 + D2) / 2 so the pulleys do not overlap.
- 4 Pick the belt type: Select Open belt, Crossed belt, or V-belt (open) for the matching drive geometry.
- 5 Read the total belt length and wrap angles: The Total belt length row returns the cut length in millimetres. The Wrap angle rows return the arc of contact on each pulley in degrees.
- 6 Reset and try another drive: Click Reset to restore the default 200/100/400 mm drive, then change any input.
For a 200 mm motor pulley and a 100 mm driven pulley with a 500 mm center distance on an open belt, enter D1 = 200, D2 = 100, C = 500, and Belt type = Open belt. The result panel returns Total belt length = 1476.24 mm and wrap angles of 191.48 and 168.52 degrees.
When the drive is a timing belt on a passenger-car engine and the next question is when to replace it, the timing belt interval calculator returns the service interval and the working life in miles or kilometres.
Benefits of Using This Calculator
These benefits show up in the workshop and the design office when the belt length is no longer calculated by hand for every drive.
- • Three belt modes in one panel: Switch between open belt, crossed belt, and V-belt without leaving the form.
- • Two pulley diameters and one distance are the only inputs: Enter D1, D2, and C once and the result panel returns the belt length and the wrap angles.
- • Wrap angles surface slip risk early: The wrap-angle readouts tell you whether the belt will grip each pulley.
- • Real-time recalculation as inputs change: Edit any field and the result panel updates immediately.
- • Cut-length or standard V-belt size ready to order: The Total belt length row returns the cut length for a flat belt or the pitch-line length to look up against a V-belt size chart.
Most workshops have a small inventory of standard V-belt sizes and a stockpile of flat belt material, so a calculator that returns both the total belt length and the wrap angles saves a trip to the bench to mock up the drive with a piece of string.
When the two pulleys are a crankshaft pulley and a supercharger pulley and the question is how the ratio changes boost, the supercharger pulley ratio calculator returns the speed ratio and the resulting boost for any pulley swap.
Factors That Affect Your Results
Four factors decide the readouts in the result panel, plus two limitations when the drive does not match the textbook assumptions.
Difference between the two pulley diameters
The correction term (D1 - D2)^2 / (4*C) grows as the pulleys get further apart in size.
Center distance relative to pulley size
When C is much larger than D1 + D2 the correction term becomes negligible. When C is close to (D1 + D2)/2 the correction term dominates.
Open belt versus crossed belt
A crossed belt drive is longer than an open belt drive on the same two pulleys, because the correction term uses (D1 + D2)^2 instead of (D1 - D2)^2.
V-belt cross-section height
A V-belt rides on the pitch diameter rather than the outer diameter, and the belt body above the pitch line adds a few millimetres to the cut length.
- • The formula assumes the two pulleys are in the same plane and parallel. Real drives with misaligned shafts or out-of-plane pulleys add a small extra length that this calculator does not estimate.
- • The V-belt correction constant is a typical 9 mm for common cross-section heights. Larger or smaller V-belt sections (SPZ, SPA, SPB, SPC) will produce a slightly different correction.
Treat the readouts as the textbook prediction of the belt length under ideal geometry. Real drives add a small amount for belt stretch under tension, so most workshops round the cut length up by 1-2 percent.
According to SDP-SI - Belt Length Calculator, the correction term depends on the square of the diameter difference (open) or diameter sum (crossed) divided by four times the center distance, which is why the four factor cards above change the readouts.
When the tensioned belt span is long enough that span vibration matters, the vibration natural frequency calculator returns the natural frequency of a tensioned cable or belt from its mass per unit length and the working tension.
Frequently Asked Questions
Q: How do you calculate belt length between two pulleys?
A: Measure the two pulley outer diameters D1 and D2 and the center-to-center distance C, then apply the textbook formula. For an open belt, L = 2*C + (pi/2)*(D1 + D2) + (D1 - D2)^2 / (4*C). For a crossed belt, the correction term uses (D1 + D2)^2 instead of (D1 - D2)^2. This belt length calculator does the arithmetic and returns the total belt length plus the wrap angle on each pulley.
Q: What is the formula for an open belt drive?
A: The open belt length on two pulleys is L = 2*C + (pi/2)*(D1 + D2) + (D1 - D2)^2 / (4*C). The first term 2*C is the sum of the two straight runs, the second term (pi/2)*(D1 + D2) is the half-circumference of a circle whose diameter equals the sum of the two pulley diameters, and the last term is the small correction that accounts for the offset of the tangent points.
Q: What is the formula for a crossed belt drive?
A: A crossed belt drive has the same first two terms but a different correction term, so L = 2*C + (pi/2)*(D1 + D2) + (D1 + D2)^2 / (4*C). The sum appears instead of the difference because the two straight runs cross between the pulleys and each straight run has to swing around the other pulley before reaching its tangent point.
Q: What is the difference between open belt and crossed belt?
A: An open belt runs in parallel between two pulleys without crossing, so the belt does not twist and both pulleys can rotate in the same direction. A crossed belt twists 180 degrees between the two pulleys, which reverses the direction of rotation at the second pulley and increases the wrap angle on each pulley above 180 degrees. The crossed belt is also longer than the open belt on the same two pulleys.
Q: Does belt length change with center distance?
A: Yes. The 2*C term in the formula means a small change in center distance translates almost directly into the same change in belt length. Increasing the center distance by 10 mm lengthens an open belt by about 20 mm, and the (D1 - D2)^2 / (4*C) correction term shrinks as C grows. For very large center distances the belt length approaches 2*C + pi*(D1 + D2)/2.
Q: How do you size a V-belt for a two-pulley drive?
A: Measure the pitch diameter of each sheave, not the outer diameter, and enter those numbers plus the center distance in the belt length calculator. The V-belt mode in this panel returns the pitch-line length, which is the number to look up against a V-belt size chart (SPZ, SPA, SPB, SPC and the equivalent A/B/C/D sections) and then pick the next standard size up. Add a small take-up allowance for tensioner travel.
