Cubic Yards Cylinder Calculator - Volume in Cubic Yards, Gallons, and Liters

A cubic yards cylinder calculator is a focused geometry tool that converts the radius or diameter and height of a right circular cylinder into volume expressed in cubic yards, alongside equivalent values in cubic feet, cubic inches, cubic meters, liters, and US gallons. It is built for situations where the answer must come out in yards - such as ordering ready-mix concrete for a cylindrical pier, sizing a large rainwater cistern, or estimating the capacity of a vertical storage silo - and the linear dimensions are read from a tape measure, blueprint, or product spec sheet.

• • Concrete Test Cylinders: Convert the diameter and height of a 6 inch by 12 inch concrete test cylinder into cubic yards, cubic feet, and gallons for density and compressive-strength reporting.
• • Ready-Mix Concrete Cylindrical Piers: Estimate the cubic yards of ready-mix concrete needed to pour a cylindrical sonotube pier when the diameter and depth are measured in feet or inches.
• • Large Rainwater and Irrigation Cisterns: Compute the holding capacity of a vertical cistern or tank in cubic yards and US gallons from the inner diameter and height.
• • Silo and Grain Bin Capacity: Estimate the interior volume of a vertical silo or grain bin in cubic yards so truckload quotes and aeration fan specs can be compared directly.

Many product spec sheets list dimensions in feet or inches while concrete and aggregate orders are quoted in cubic yards, which forces a two-step conversion. The cubic yards cylinder calculator keeps the inputs in whatever unit you measured in - yards, feet, inches, or meters - and produces the cubic yards answer in a single pass.

For a more general cylinder tool that does not anchor on cubic yards, see our cylinder volume calculator, which lists the same formula in a more abstract form.

The cubic yards cylinder calculator squares the base radius, multiplies by the height, and applies pi to find the geometric volume in the selected linear unit. The result is converted to cubic yards using NIST-anchored unit ratios so cubic yards is always the primary answer, with cubic feet, cubic inches, cubic meters, liters, and US gallons listed as secondary conversions.

• r (radius): Distance from the center of the circular base to its edge, expressed in the chosen unit. Enter d/2 manually or select Diameter to have the calculator halve it for you.
• d (diameter): Full width of the circular base through the center. Choose Diameter mode so the calculator uses d/2 as the radius.
• h (height): Perpendicular height of the cylinder along its central axis, in the same unit as r or d.
• pi: Mathematical constant approximately equal to 3.14159265359, applied to convert the circular base area into a volume.

The conversion from cubic yards to the secondary units uses 1 yd^3 = 27 ft^3, 1 yd^3 = 46656 in^3, 1 yd^3 = 0.764554857984 m^3, 1 yd^3 = 764.554857984 L, and 1 yd^3 = 201.974025974 US gal. These ratios come from the NIST definition of the yard, so the cubic yards primary output and every secondary value are traceable to a single source.

When you change the linear unit selector, the calculator rescales the base and height to yards before applying the formula. The cubic yards value stays consistent across units, while the secondary outputs simply reflect the larger or smaller underlying cylinder.

According to Wolfram MathWorld, the volume of a right circular cylinder of radius r and height h is V = pi * r^2 * h.

If the spec sheet is in feet rather than yards, the cubic feet cylinder calculator anchors the same formula on cubic feet without re-entering the dimensions in a different unit.

Four ideas keep the math grounded: the geometric formula itself, the unit ratios that power the conversions, the difference between radius and diameter, and the connection between cubic yards and US gallons for liquid capacity.

When the cylinder is hollow, like a pipe wall, the inner radius and outer radius produce different volumes. Treat the wall as a separate outer cylinder and subtract the inner cylinder's volume for the material volume of the pipe itself.

Once the cubic yards figure is known, the cubic yards to tons calculator converts it into tons for a chosen material density such as gravel, sand, or concrete.

Enter the base dimension, height, and unit, and the calculator updates every output the moment any field changes.

1. 1 Pick Radius or Diameter: Use the Base Input selector to tell the calculator whether the value you are about to type is the radius (half the width) or the full diameter of the circular base.
2. 2 Enter the Base Dimension: Type the measured radius or diameter in the numeric field. Yards are the most common default for large cylinders, but any of the four units work.
3. 3 Enter the Cylinder Height: Provide the perpendicular height of the cylinder in the same unit. For a horizontal concrete pipe, the height is the length of the pipe.
4. 4 Choose the Linear Unit: Select yards, feet, inches, or meters so the calculator can convert both base and height to yards before applying the formula.
5. 5 Read the Outputs: Read the primary cubic yards value, then scan the secondary row for cubic feet, cubic inches, cubic meters, liters, and US gallons when you need them.

For a 1 yd radius by 2 yd tall rainwater cistern: the user picks Radius, enters 1 in the base field, enters 2 in the height field, and leaves the unit selector on Yards. The calculator shows about 6.28 yd^3, which converts to roughly 1269.0 US gallons of usable capacity.

For tanks that are partly full, lay on their side, or use a non-cylindrical shape, switch to the tank volume calculator, which supports those layout-specific cases.

The biggest advantage of a dedicated cubic yards cylinder tool is that the primary unit, the conversion ratios, and the geometric formula all live in one place.

• • Anchored to Cubic Yards: The primary output is always cubic yards, the unit used in ready-mix concrete orders, landscape aggregate quotes, and US excavation estimates.
• • Pick the Unit You Measured In: The shared linear unit selector accepts yards, feet, inches, or meters for both the base dimension and the height, so a nameplate in inches and a spec sheet in meters do not need to be reconciled by hand.
• • Full Capacity in One View: See cubic yards, cubic feet, cubic inches, cubic meters, liters, and US gallons at the same time, so capacity quotes from different suppliers can be compared directly.
• • Avoids Pi Mistakes: The math engine uses the full double-precision value of pi, eliminating the rounding error that creeps in when pi is typed by hand as 3.14.
• • Tape-Measure Friendly: Inputs accept decimals, so a 1 foot 9 inch radius can be entered as 1.75 (yards) or 5.25 (feet) without first converting it to a fraction.

If the project has shifted from a tank to a flat rectangular excavation, a cubic yard calculator is the better fit because it works on length, width, and depth rather than radius and height.

Three variables drive how much the actual volume can differ from the geometric answer: which diameter you measured, which unit the spec sheet is in, and whether the cylinder is hollow.

• • The calculator assumes a right circular cylinder with flat, parallel bases. Tapered tanks, domed ends, and horizontal cylinders require different formulas.
• • The output is a geometric volume, not a wet volume. The calculator does not account for headspace, fill levels, fittings, or thermal expansion of the contents.

The conversion factors that take cubic yards into cubic feet, cubic inches, cubic meters, liters, and US gallons come from the NIST definition of the yard, so the secondary values stay accurate across any size of cylinder. Pi itself is a mathematical constant and does not vary with the cylinder, but if the working temperature is far from 20 degrees Celsius, the linear dimensions can shift slightly; for everyday tape-measure work the geometric value is well within the tolerance of the measurement.

According to National Institute of Standards and Technology (NIST), the yard is defined as exactly 0.9144 meters, which fixes 1 cubic yard at 0.764554857984 cubic meters and 764.554857984 liters.

For a cylindrical sonotube pier, the concrete calculator adds a waste factor and converts the cubic yards of concrete into bag counts for both 60 lb and 80 lb sacks.
