An ellipse calculator turns the standard-form ellipse equation (x - c1)^2 / a^2 + (y - c2)^2 / b^2 = 1 into a complete picture of the curve: area, perimeter, eccentricity, the two foci, and the four vertices. You type in the two semi-axes a and b and the center point (c1, c2), and the tool does the algebra and the unit bookkeeping for you. It is the fastest way to solve an ellipse equation when you already know a, b, and the center but still need the focus coordinates, the vertex list, or the enclosed area in real units.

• • Solve an ellipse equation for the four vertices: Drop in a = 5 and b = 3 with the origin as the center to get the four vertices without re-deriving the formula by hand.
• • Find the foci from the standard form: Enter a and b, then read the two focus coordinates for a sketch, an orbit, or a conic-sections problem.
• • Compute the area and perimeter of a real oval: Use a garden-bed, pool, or tabletop oval in cm, m, mm, in, or ft to get the enclosed area and boundary length.
• • Check eccentricity, focal distance, and orientation: Compare horizontal versus vertical ellipses, see how e = c / a approaches 1 as the oval gets thinner, and switch the major axis.

The standard-form equation is the easiest entry point because every ellipse can be rotated or translated to fit it, and the two semi-axes plus the center are the only three pieces of information you really need.

For the special case a = b the curve becomes a circle, and the formula collapses cleanly to a = b, c = 0, e = 0, perimeter 2 pi a.

For a calculation that stays focused on the area and perimeter only, ellipse area calculator covers just the two semi-axes without the center or the orientation toggle.

The calculator takes the two semi-axes and the center, normalizes a to be the larger of the two so it is always the semi-major axis, and evaluates the analytic geometry formulas for area, perimeter, focal distance, eccentricity, and the focus and vertex coordinates. The major axis can be aligned to x or y, which only changes whether the foci and vertices sit on the horizontal or vertical line through the center.

• a: Semi-major axis, the longer of the two semi-axes.
• b: Semi-minor axis, the shorter of the two semi-axes.
• c1, c2: Center coordinates. Every other output adds (c1, c2) to the origin-based value.
• c: Focal distance, c = sqrt(a^2 - b^2). Distance from the center to either focus.
• e: Eccentricity, e = c / a. Lies in [0, 1); 0 for a circle, approaching 1 for a long thin ellipse.

The standard-form equation is the entry point because it is the only form where the semi-axes, the center, and the orientation are visible directly.

Perimeter has no exact closed form, so the calculator uses Ramanujan's first approximation, which MathWorld Wolfram cites as accurate to better than 0.04 percent for aspect ratios up to about 3 to 1.

According to Paul's Online Math Notes - Conic Sections.

According to MathWorld Wolfram - Ellipse.

When a equals b the curve collapses to a circle, and the same standard-form approach feeds into circle equation calculator with one fewer variable to track.

Four ideas make every ellipse result predictable. They also tell you what the calculator is doing behind the scenes so you can sanity-check the outputs.

These four concepts are enough to interpret any answer the calculator produces.

If the ellipse is rotated, the standard form has an xy cross term. Solve for the rotated a, b, and center first, then come back to this tool.

Ellipses share the conic-section family with parabolas and hyperbolas, so parabola calculator is a useful follow-up if you need a single focus and directrix instead of two foci.

The calculator expects a, b, the center point, the orientation, and the length unit. Five quick steps are enough to read off the full ellipse description.

1. 1 Measure or read the two semi-axes: Find the semi-major axis a (half the longest span) and the semi-minor axis b (half the shortest span). Both must be non-negative.
2. 2 Pick the center point: Read the center (c1, c2) from the equation or from the midpoint of the two major-axis vertices, then type those numbers into the Center x and Center y fields.
3. 3 Choose the major-axis orientation: If the major axis is along the x direction, leave Orientation on Horizontal. If it runs along y, switch it to Vertical.
4. 4 Set the length unit: Pick cm, m, mm, in, or ft. The unit applies to the input semi-axes and to every length and area output.
5. 5 Read the results panel: Scan the area, perimeter, focal distance, eccentricity, and the eight coordinates. The standard-form equation is shown at the top as a sanity check.

For a tabletop oval that is 100 cm across the long way and 60 cm across the short way, centered at point (60, 40), type a = 50, b = 30, c1 = 60, c2 = 40, leave orientation on Horizontal, and pick cm. The panel reads area 4712.389 cm^2, perimeter 176.715 cm, foci at (100, 40) and (20, 40).

If your oval is being approximated as a polygon of equally spaced points, polygon area calculator handles the vertex-list version of the same area question.

The value of the calculator is that it keeps the algebra and the unit bookkeeping in one place so the answer is consistent across every quantity.

• • One input form, ten outputs: Three numeric inputs give you the area, perimeter, eccentricity, focal distance, two foci, and four vertices in a single pass.
• • Unit-aware area and length: Pick cm, m, mm, in, or ft once and every length and area output uses the same unit.
• • Handles horizontal and vertical ellipses: Switch the orientation toggle to put the major axis on the y direction and the calculator relabels the focus and vertex coordinates.
• • Covers the circle special case: When a = b the focal distance drops to 0, eccentricity becomes 0, and the perimeter becomes 2 pi a.
• • Catches obvious input mistakes: Negative semi-axes, missing values, and a = 0 are all handled with clear messages and zero outputs.

The single-form input is the main time-saver. The most common error when solving an ellipse by hand is forgetting the sign of the focal distance or putting the major axis on the wrong side of the center.

Unit awareness matters when the same ellipse is described in two unit systems. The length unit, the focal distance, and the area all switch together.

When the equation is given in general form or as three boundary points, center of ellipse calculator finds the center (c1, c2) you can then type back into this calculator.

A handful of geometric and numerical factors decide which numbers you see in the result panel and how accurate the perimeter estimate is.

• • Ramanujan's first perimeter approximation is an estimate. It is accurate to better than 0.04 percent for aspect ratios up to about 3 to 1, but the error grows as the ellipse gets thinner.
• • The calculator assumes the ellipse is in standard form with axes parallel to the coordinate axes. A rotated ellipse is not in standard form, so its a, b, and center must be computed from the rotated coefficients first.
• • When a = 0 or b = 0 the curve is no longer an ellipse. The calculator reports the limiting values (area 0, perimeter 4 times the surviving semi-axis, eccentricity 1), so the result is still well defined, but the geometry has collapsed to a line segment.

Aspect ratio is the single most influential factor. It changes the eccentricity, the shape, the perimeter error, and the visible stretch.

Center offset and orientation move the absolute coordinates but leave the dimensionless ratios alone.

According to MathWorld Wolfram - Eccentricity.
