Magnetic Force On Current Carrying Wire Calculator
Results
What Is the Magnetic Force on a Current Carrying Wire Calculator?
The magnetic force on current carrying wire calculator tells you how hard a magnetic field pushes on a straight wire that carries electric current. You enter the magnetic field strength, the current, the length of wire sitting in the field, and the angle between the wire and the field, and the tool returns the force in newtons using F = B I L sin(theta).
This relationship is the macroscopic version of the Lorentz force. Each moving charge inside the wire feels the field, and adding up every charge across the whole length gives a single sideways push on the conductor. It shows up whenever current runs through a field: a speaker coil, a motor winding, a railgun rail, or a length of busbar near a strong magnet. The same sideways push is what makes a compass needle swing when you hold a live wire nearby, which is a quick way to feel the effect with your own hands.
If you already know two currents and want the pull between them, the magnetic force between wires calculator is the closer tool, because that one starts from the field each wire makes.
How the Calculator Works
The magnetic force on current carrying wire calculator uses one compact equation from electromagnetism. The magnitude of the force on a straight conductor is F = B I L sin(theta), where B is the magnetic flux density in tesla, I is the current in amperes, L is the length of wire inside the field in meters, and theta is the angle between the current direction and the field.
The sin(theta) term is the whole story about direction. A field that points straight along the wire (theta = 0) has no perpendicular component, so it exerts no sideways push and F = 0. As you rotate the wire toward perpendicular (theta = 90), sin(theta) climbs to 1 and the force reaches its maximum, F = B I L. Any field you feed in is treated as the component that actually matters: only the part crossing the wire does work.
For a single moving charge the underlying law is the Lorentz force; integrating that across all the charge in a straight conductor is exactly where F = B I L sin(theta) comes from. Wikipedia's Lorentz force article walks through that integration if you want the derivation rather than just the result.
Read the inputs: B = 0.5 T, I = 10 A, L = 0.2 m, theta = 90 degrees. Compute sin(90) = 1, so the full field crosses the wire. Multiply: F = 0.5 x 10 x 0.2 x 1 = 1.0 N. Tilt to 30 degrees and sin(30) = 0.5, so F drops to 0.5 N. Result: F = 1.0 N (0.5 N at 30 degrees).
HyperPhysics lays out the same F = I L B sin(theta) magnitude and the right-hand rule for direction.
Key Concepts Explained
B is the strength of the external magnetic field in tesla. Earth's field is roughly 25 to 65 microtesla, a fridge magnet is around 0.005 T, an MRI scanner reaches 1.5 to 3 T, and research magnets can exceed 10 T. The force scales directly with B, so doubling the field doubles the push. The magnetic field overview on Wikipedia covers how only the perpendicular component matters. In practice you read B from the magnet's spec sheet or measure it with a gaussmeter before relying on the number.
I is the charge flow in amperes. More current means more moving charges inside the wire, so each one adds its own small force and they sum linearly. A 0 A wire feels nothing because there are no moving charges to act on; this is why the result is exactly zero when current is zero. A typical bench supply might push a few amps, while a motor lead can carry well over a hundred, and the force scales right along with that.
L is only the part of the conductor that actually sits inside the field. If a 2 m wire passes through a 0.5 m magnet, use 0.5 m. The force is proportional to L, so a longer exposed segment simply accumulates more push from more charge in the field.
Theta is the angle between the wire and the field, measured 0 to 90 degrees. The result depends on sin(theta): 0 at parallel, 1 at perpendicular. Because sin is symmetric about 90 degrees, 30 and 150 degrees give the same magnitude, which is why the input is clamped to 0-90 for a straight wire. If you know the wire runs at some other angle, just take its supplement down to the 0-90 range before typing it in.
The field a wire itself produces near it is found with the magnetic field of a straight wire calculator, which is the reciprocal half of the force question when a second conductor is involved.
How to Use This Calculator
Enter the magnetic field B. Type the external field strength in tesla. If you only know the magnet's rating in gauss, divide by 10,000 before typing it in.
Enter the current I. Type the current the wire is carrying in amperes at the moment you care about.
Enter the wire length L. Type the length in meters of the wire that is actually inside the field, not the whole spool.
Enter the angle theta. Type the angle in degrees between the wire and the field. Use 90 for a wire across the field and 0 for a wire along it.
Read the force F. Read the force in newtons. Multiply by about 0.102 to convert to kilogram-force if you think in weight.
Benefits of Using This Calculator
The magnetic force on current carrying wire calculator gives you the force for any angle at once, so you can see at a glance how rotating a conductor changes the mechanical load without reworking sines by hand.
The magnetic force on current carrying wire calculator makes the role of each variable explicit, which helps students build intuition for why a wire parallel to a field feels nothing and a perpendicular one feels the most.
Because it reports in newtons, you can compare the magnetic push against the wire's own weight or the clamping force in a mount and judge whether the support is adequate. For a long overhead busbar, even a modest field can add up to a measurable sideways load once the exposed length grows, so checking the number early avoids surprises during installation.
It is a fast sanity check before a lab: enter your planned B, I, and L and confirm the force is small enough to be safe, or large enough to measure on a balance.
Linking it with the magnetic field of a solenoid calculator lets you chain two ideas: first find the field a coil makes, then find the force that field puts on a nearby conductor.
Factors That Affect Your Results
Field strength, current, and exposed length all scale the force linearly, so a small change in any one of them moves the answer by the same fraction. The angle is the only nonlinear factor through sin(theta). If you double the current and also double the exposed length, the force goes up by four times, which is why long, high-current runs near magnets need the most care.
The formula assumes a uniform field over the length L. Near the edge of a magnet the field weakens and curves, so the true force is a little lower than the ideal number.
The tool treats a straight segment; a loop or coil has forces on each side that can partly cancel, which is why a coil torque problem needs a different treatment than a single straight wire.
Temperature and resistance are not in the equation. The current you enter is taken as given; the tool does not compute how heating or supply voltage would change I. Pair it with an Ohm's law calculator when the current itself depends on the circuit.
The result is the magnitude only and ignores the force's direction beyond the right-hand rule. It also assumes non-relativistic speeds and a rigid, straight conductor in a steady field.
Frequently Asked Questions
Q: What is the formula for the magnetic force on a current carrying wire?
A: The magnitude is F = B I L sin(theta), where B is the magnetic field in tesla, I is the current in amperes, L is the length of wire inside the field in meters, and theta is the angle between the wire and the field. Multiply the field, current, and length, then by the sine of the angle.
Q: Why does the angle between the wire and the magnetic field matter?
A: Only the component of the field that crosses the wire pushes on it. sin(theta) captures that crossing component: at 0 degrees the field runs along the wire and contributes nothing, while at 90 degrees the whole field is perpendicular and the force is at its maximum.
Q: When is the magnetic force on a wire zero?
A: The force is zero whenever sin(theta) is zero, which happens at theta = 0 degrees (wire parallel to the field), or whenever the current is zero, or whenever no part of the wire sits in the field. In each case the perpendicular field component that does the pushing is absent.
Q: How is this different from the force between two wires?
A: This tool uses a field you supply directly to find the force on one wire. The magnetic force between wires calculator instead finds the field that one current creates and uses it to find the force on the other wire, so it needs both currents and their spacing rather than an external field value.
Q: What unit is the magnetic force reported in?
A: The force is reported in newtons. If you prefer weight units, 1 N is about 0.102 kilogram-force, so you can divide the result by roughly 9.81 to compare it against the weight the wire can support.
Q: Can the wire experience a force if it is parallel to the field?
A: No. When the wire runs parallel to the magnetic field the angle is 0 degrees and sin(0) = 0, so the force is exactly zero regardless of how strong the field or current is. Only a perpendicular component of the field can push the conductor sideways.
